Use MySQL Workbench to quickly generate EER diagrams from existing databases. The specific steps are: 1. Create a new model in Model Explorer; 2. Select "Create EER Model from Existing Database" and configure database connections; 3. Enter the reverse engineering process and select the tables and other objects to be imported; 4. After the generation is performed, view the EER diagram and manually adjust the missing associations; 5. Export the chart to PNG or PDF format for sharing. The entire process relies on foreign key constraints to ensure the accuracy of the relationship. If there is no foreign key, it needs to be supplemented manually.

If you already have a ready-made MySQL database and want to quickly generate EER graphs (enhanced entity relationship graphs), MySQL Workbench is a very practical tool. It can reversely generate EER graphs directly from the database structure, helping you understand the relationships between tables more intuitively.

Below are some practical operation suggestions and precautions to help you complete this process smoothly.

Open Model Explorer and create a new model

In the MySQL Workbench main interface, click the "Model" icon on the left to enter Model Explorer. Here you can create a new model file to store your EER diagram.

• Click "Create a new EER Model from existing database"
• Select the configured database connection
• Fill in the database name to import (default is the current database in the connection)

After this step is completed, the tool will start loading the database structure, including all tables, fields, indexes, foreign keys and other information.

Reverse engineering to generate EER diagrams

Next, we will enter the "Reverse Engineer" process, which is the core part of the entire operation.

1. Connect to the database : Confirm that the correct connection configuration is used.
2. Select the object to import :
   • You can select all tables or manually check a few specific tables
   • Objects such as views, stored procedures, etc. can be selected as needed
3. Generate model : After clicking "Execute", the system will automatically analyze the database structure and generate the corresponding EER diagram.

During this process, if there are no foreign key constraints between certain tables, the EER graph may not automatically generate an association line. At this time, you need to manually adjust or supplement foreign key relationships.

View and adjust EER charts

After the generation is complete, you will see a visual chart showing the relationship between the tables. you can:

• Drag the table to retype it to make the structure clearer
• Double-click the table to view field details, indexes, foreign keys, etc.
• Add comments or graphic descriptions to facilitate understanding when teamwork

Sometimes too many tables can cause confusion in the chart. You can consider exporting them in modules, or just select a few associated forms to model separately.

If you find that some relationships are not displayed, check whether foreign key constraints are set. EER diagrams rely on foreign keys to establish connections. If there are no foreign keys, you need to manually add relationship lines.

Export and share EER pictures

After editing, you can export the EER image as an image or PDF file for easy sharing or archive.

• Click File > Export > Export as PNG or PDF in the menu bar
• Set the save path

In addition, you can save the entire model file (.mwb format) and continue to edit it after opening it next time.

Basically these steps. Although it seems a bit too many, the whole process is actually very fast after getting familiar with it. The key is to ensure that there is a good foreign key design in the database so that the generated EER diagram is accurate and valuable for reference.
