Implementing High Availability Solutions for MySQL
Jul 06, 2025 am 02:04 AMThe core of MySQL high availability solution lies in master-slave replication, automatic failure switching, data consistency guarantee and backup policies. The specific steps are as follows: 1. Build master-slave replication, recommend asynchronous or semi-synchronous replication, and enable GTID and relay log; 2. Introduce tools such as MHA and Orchestrator to achieve automatic switching of failures, pay attention to monitoring frequency and data integrity; 3. Use pt-table-checksum regularly to verify data consistency, and write operations should be given priority to the main library; 4. Develop backup strategies, backup full-time and hourly incremental daily, and test the recovery process regularly.
MySQL's high availability solution is to make the database not go down or serve continuously as much as possible. There are many ways to implement it, but the core ideas are just a few: master-slave replication, failover, and data consistency guarantee. Let’s talk about how to do it in a few practical directions.

Master-slave replication is the basis
If you want to make high availability, the first step is to set up master-slave copying. This thing is to allow one or more slave libraries to synchronize the data of the master library in real time. Once there is a problem with the master library, you can quickly switch to the slave library to continue providing services.

- The most common practice is to use asynchronous replication, which has low latency and good performance, but may lose data;
- If the data consistency requirements are high, semi-synchronous replication can be used to ensure that at least one transaction is received from the library and then submitted;
- Remember to enable GTID and relay log when building, so that failure recovery is more convenient;
- It is best to have similar hardware configurations to the main library, otherwise it is easy to cause problems if the synchronization cannot keep up.
How to do automatic fault switching?
It’s not enough to have a master or slave alone, but you still have to be able to switch “automatically”. Manual cutting is too slow and can easily make mistakes, so some tools have to be introduced to monitor and switch.
Common solutions:

- MHA (Master High Availability) : an old tool, suitable for small clusters, can automatically detect the failure of the main library and elect new masters;
- Orchestrator : It is used more frequently now, has a friendly interface and supports multiple topological structures;
- ProxySQL MGR : If you are using MySQL Group Replication, it will be very stable to combine ProxySQL for routing;
No matter which tool you use, you must pay attention to:
- The monitoring frequency cannot be too high or too low;
- Before switching, confirm the data integrity of the slave library;
- After cutting, the notification mechanism should be kept up, such as sending an email or DingTalk reminder.
Data consistency is more important than you think
Many people only focus on whether they can cut it, ignoring whether the data is consistent. If the transaction has not been transmitted when the main library is dead, forced switching will lead to data loss or inconsistency.
suggestion:
- To regularly verify the consistency of master-slave data, you can use the pt-table-checksum tool;
- Try to go to the main library when writing operations are as much as possible, and read operations can be scattered to the slave library;
- If you are using MGR or InnoDB Cluster, data consistency is guaranteed by the in-group protocol, which saves a lot of worry;
- Avoid long transactions, especially write operations, which can easily slow down the copy progress.
Don't forget the backup and recovery strategies
High availability is not omnipotent. What if the entire cluster is out of date? Backup is always the lowest level of security network.
- Make a full backup every day and incremental backup every hour;
- Use mysqldump and xtrabackup to do all of them. The key is to regularly test the recovery process;
- Put the backup files on other machines or even other computer rooms to avoid local disasters;
- The automated recovery script is ready and you won’t be in a hurry at critical moments.
Basically that's it. High availability seems complicated, but in fact, it is to set up the master and slave, automatically cut the fault, no problem with the data, and restore the backup at any time. It's not difficult, but there are many details, and you'll get stuck in the pit if you are not careful.
