How to connect to a remote database using mysql workbench
Jun 30, 2025 am 01:44 AMTo use MySQL Workbench to connect to a remote database, 1. Ensure that the remote database allows external connections, including configuring binding IP, opening firewall ports, and setting user permissions; 2. Create a new connection in Workbench, fill in the host name, port, user name and password, and test the connection; 3. If you cannot connect directly, you can establish a secure connection through SSH tunnel; 4. Pay attention to troubleshooting common problems such as connection timeout, access denial, and slow connection. After correct configuration, connecting to the remote database is not complicated, but attention should be paid to details.
Connecting to remote databases is very common during development and debugging, especially when your local environment needs to access the MySQL database deployed on the server. MySQL Workbench is a commonly used tool that supports not only local connections, but also fully supports remote connections.

Ensure that the remote database allows external connections
Before using MySQL Workbench to connect, first confirm that the target database server allows connections from your IP address:

- Check the MySQL configuration file (usually
my.cnf
ormy.ini
) to make sure that it is not bound to127.0.0.1
, but is bound to 0.0.0.0.0 or a specific open public IP. - Confirm whether the security group rules of the firewall or cloud platform release the port used by MySQL (default is 3306).
- Make sure the database user has permission to log in from your IP. For example, you can use the following statement to create a user:
CREATE USER 'your_user'@'your_ip' IDENTIFIED BY 'password'; GRANT ALL PRIVILEGES ON *.* TO 'your_user'@'your_ip'; FLUSH PRIVILEGES;
Configuring Remote Connections in MySQL Workbench
After opening MySQL Workbench, you can set up a remote database by creating a new connection:
- Click the " " sign to add a new connection
- Fill in the connection name (such as Remote DB)
- Fill in the remote server's IP or domain name
- The default port is 3306, unless customization is done
- Fill in the username and password for your permissioned account information
- You can click "Test Connection" to test whether it can be connected
If the test fails, remember to check the aforementioned database configuration, network policy, and user permissions issues.
![]()
SSH tunnel connection method (optional)
If your remote server does not allow direct access to port 3306, but you can log in to the server via SSH, you can use an SSH tunnel to connect:
- Switch to the "SSH" tab in Connection settings
- Check "Use SSH connection to remote host"
- Fill in the SSH host address, port (usually 22), username and password or key path
- The local MySQL service will connect to the remote database through this tunnel
This method is safer and suitable for production environment connection.
Frequently Asked Questions and Precautions
- Connection timeout : It may be because the network is blocked or the firewall is restricted. It is recommended to ping and telnet first to test network accessibility.
- Access denied : Confirm that the user's permissions and password are correct, and allow logging from your IP
- Slow connection : If the remote server has limited bandwidth, it may affect query speed, consider compressing transmission or optimizing SQL
Basically these are the key points. As long as the remote server is configured properly and the correct connection parameters are added, it is not complicated to use MySQL Workbench to connect to the remote database, but some details are easy to ignore.
The above is the detailed content of How to connect to a remote database using mysql workbench. For more information, please follow other related articles on the PHP Chinese website!
